DESCRIPTION
Frequency : 10 kHz – 10 mHz frequency area
Mountings : Through-hole, SMD, Flying leads, terminals,etc
Construction forms: EE /EP/EPC/ EFD /ER/ RM / ETD / U / P /PQ / Toroid core ,etc
Cores: Ferrite / Iron powder / Carbon Mu / Sendust / High Flux / MPP / Amorphous / Nanocrystalline ,etc
Copper: PUR(UEW), PEI, TIW, litz, Foil
Topology : Flyback, Forward, Push- pull, Full bridge, Half bridge, LLC ,Gate Drive, Current Sense,Buck,Boost,etc
Winding structure: Single/double/triple isolated winding wires, depending on the desired insulation class
Application: Industrial Electronics,Lighting Designs,Power/Industrial Controls,Computer equipment,Internet equipment,AC main power supply system,Industrial control,Telecom equipment.
Type of switching power transformer:
•Pulse transformer /EFD series/EEL series/ER series /RM series /EP series /EPC series /EE series/EE series /ERL series/EC series/ETD series/PQ series
Advantages for Switch-mode power supply (SMPS) transformers
1. High Efficiency: SMPS transformers use high-frequency operation, which reduces energy loss and improves energy utilization. Compared to traditional transformers, SMPS transformers have higher efficiency.
2. Compact Size: Since SMPS transformers operate in a high-frequency range, smaller magnetic cores and windings can be used, enabling a compact design.
3. Light weight: Due to the smaller size of SMPS transformers, they require relatively fewer materials, making them lighter and suitable for portable electronic devices.
Kunyo is a well-known high-quality custom transformer manufacturer. And we develop custom magnetic transformer components and they are widely used in several industrial applications.
– Custom transformers for aerospace,railway
– Audio transformers, audio isolation transformers and audio output transformers
– Medical isolation transformers
– Industrial equipment power transformers and electrical transformers
– Household appliance SMPS transformers
– Scientific instrument custom transformer
– Transformers for class A and class B fire alarms
Custom Transformer Production Line
Custom Transformer Quality Assurance System
Established in 2013, Shenzhen Kunyo Technology is committed to designing and manufacturing custom magnetic components, including high-frequency transformers, low-frequency transformers, audio transformers, power transformers, and inductors.
