We offer a very large standard program of magnetic components, with the industry experience and technology accumulation ,and we have technical strength in the field of low power (1-50KVA), low medium frequency transformer, and we have unique process equipment for producing the high voltage products (3KV-20KV)
Special Features:
Special Design – Custom Design . Pls send us your detailed spec and we will customize the transformer for you.
| Power Rating | EI TYPE | Ref Core Size | Dimension(mm) | ||
| L | W | H | |||
| 10VA | EI48 | 48-18 | 50 | 34 | 44 |
| 12VA | EI48 | 48-20 | 50 | 36 | 44 |
| 15VA | EI48 | 48-24 | 50 | 40 | 44 |
| 20VA | EI48 | 48-30 | 50 | 46 | 44 |
| 25VA | EI57 | 57-20 | 59.5 | 44 | 50.5 |
| 30VA | EI57 | 57-30 | 59.5 | 48.5 | 50.5 |
| 35VA | EI57 | 57-30 | 59.5 | 54 | 50.5 |
| 40VA | EI57 | 57-35 | 59.5 | 59 | 50.5 |
| 45VA | EI66 | 66-24 | 68.5 | 52 | 58.5 |
| 55VA | EI66 | 66-36 | 68.5 | 58 | 58.5 |
| 60VA | EI66 | 66-36 | 68.5 | 64 | 58.5 |
| 65VA | EI66 | 66-40 | 69.5 | 68 | 58.5 |
| 70VA | EI66 | 66-45 | 68.5 | 71 | 58.5 |
| 80VA | EI76 | 76-32 | 78.5 | 62 | 68.5 |
| 100VA | EI76 | 76-38 | 78.5 | 68 | 68.5 |
| 120VA | EI76 | 76-45 | 78.5 | 75 | 68.5 |
| 135VA | EI76 | 76-50 | 78.5 | 80 | 68.5 |
| 140VA | EI86 | 86-38 | 86.2 | 72 | 72 |
| 145VA | EI86 | 86-42 | 86.2 | 76 | 72 |
| 155VA | EI86 | 86-45 | 86.2 | 79 | 72 |
| 155VA | EI96 | 96-32 | 96 | 69 | 80.5 |
| 170VA | EI86 | 86-50 | 86.2 | 79 | 72 |
| 180VA | EI96 | 96-38 | 96 | 75 | 80.5 |
| 210VA | EI96 | 96-45 | 96 | 82 | 80.5 |
| 230VA | EI96 | 96-50 | 96 | 87 | 80.5 |
| 230VA | EI105 | 105-34 | 105 | 73 | 91 |
| 265VA | EI96 | 96-60 | 96 | 97 | 80.5 |
| 270VA | EI105 | 105-40 | 105 | 73 | 91 |
| 340VA | EI105 | 105-50 | 105 | 89 | 91 |
| 370VA | EI105 | 105-55 | 105 | 94 | 91 |
| 400VA | EI114 | 114-45 | 114 | 89 | 97.5 |
| 430VA | EI114 | 114-50 | 114 | 94 | 97.5 |
| 480VA | EI114 | 114-55 | 114 | 99 | 97.5 |
| 520VA | EI114 | 114-60 | 114 | 104 | 97.5 |
| 560VA | EI114 | 114-65 | 114 | 109 | 97.5 |
| 670VA | EI133 | 133-50 | 136 | 115 | 114 |
| 730VA | EI133 | 133-55 | 136 | 128 | 114 |
| 800VA | EI133 | 133-60 | 136 | 125 | 144 |
| 870VA | EI133 | 133-65 | 136 | 129 | 144 |
| 930VA | EI133 | 133-70 | 136 | 135 | 144 |
| 1000VA | EI133 | 133-75 | 136 | 141 | 144 |
| 1080VA | EI133 | 133-80 | 136 | 144 | 144 |
| 1200VA | EI133 | 133-90 | 136 | 154 | 144 |
Established in 2013, Shenzhen Kunyo Technology is committed to designing and manufacturing custom magnetic components, including high-frequency transformers, low-frequency transformers, audio transformers, power transformers, and inductors.
Contact us right now to get more information, we will have people reply within 12 hours.
You can get a price of this model or send us any question to get any information you would like to know, we will reply to you soonest.
